產品特性
? 玻璃鈍化芯片
? 在10/1000μ波形重復率（占空比）：0.01%下，峰值脈沖功率可達500w
? 低漏電流
? 單、雙向單元
? 優(yōu)良的鉗位能力
? 快速的響應時間
? 通過無鉛認證，符合ROHS
機械參數(shù)
? 方法：模制塑料
? 環(huán)氧樹脂：UL 94V-0阻燃劑
? 引線：可焊性按MIL-STD-202，方法208可焊
? 極性：除雙極性外有色帶的一端為陰極
? 安裝位置：任何
| 型號 | 圖片 | 封裝 | VBR.MIN(V) | VBR.MAX(V) | IT(mA) | IR(μA) | VRWM(V) | IPP(A) | VC(V) | 下載 |
|---|---|---|---|---|---|---|---|---|---|---|
|
DO-15 |
6.40 |
7.00 |
10 |
600 |
5.0 |
54.35 |
9.2 |
|
|
|
DO-15 |
6.67 |
7.37 |
10 |
600 |
6.0 |
48.54 |
10.3 |
|
|
|
DO-15 |
7.22 |
7.98 |
10 |
400 |
6.5 |
44.64 |
11.2 |
|
|
|
DO-15 |
7.78 |
8.60 |
10 |
150 |
7.0 |
41.67 |
12.0 |
|
|
|
DO-15 |
8.33 |
9.21 |
1 |
50 |
7.5 |
38.76 |
12.9 |
|
|
|
DO-15 |
8.89 |
9.83 |
1 |
25 |
8.0 |
36.76 |
13.6 |
|
|
|
DO-15 |
9.44 |
10.40 |
1 |
5 |
8.5 |
34.72 |
14.4 |
|
|
|
DO-15 |
10.00 |
11.10 |
1 |
5 |
9.0 |
32.47 |
15.4 |
|
|
|
DO-15 |
11.10 |
12.30 |
1 |
5 |
10.0 |
29.41 |
17.0 |
|
|
|
DO-15 |
12.20 |
13.50 |
1 |
5 |
11.0 |
27.47 |
18.2 |
|
|
|
DO-15 |
13.30 |
14.70 |
1 |
5 |
12.0 |
25.13 |
19.9 |
|
|
|
DO-15 |
14.40 |
15.90 |
1 |
5 |
13.0 |
23.26 |
21.5 |
|
|
|
DO-15 |
15.60 |
17.20 |
1 |
5 |
14.0 |
21.55 |
23.2 |
|
|
|
DO-15 |
16.70 |
18.50 |
1 |
5 |
15.0 |
20.49 |
24.4 |
|
|
|
DO-15 |
17.80 |
19.70 |
1 |
5 |
16.0 |
19.23 |
26.0 |
|
|
|
DO-15 |
18.90 |
20.90 |
1 |
5 |
17.0 |
18.12 |
27.6 |
|
|
|
DO-15 |
20.00 |
22.10 |
1 |
5 |
18.0 |
17.12 |
29.2 |
|
|
|
DO-15 |
21.10 |
23.30 |
1 |
5 |
19.0 |
16.24 |
30.8 |
|
|
|
DO-15 |
22.20 |
24.50 |
1 |
5 |
20.0 |
15.43 |
32.4 |
|
|
|
DO-15 |
24.40 |
26.90 |
1 |
5 |
22.0 |
14.08 |
35.5 |
|
|
|
DO-15 |
26.70 |
29.50 |
1 |
5 |
24.0 |
12.85 |
38.9 |
|
|
|
DO-15 |
28.90 |
31.90 |
1 |
5 |
26.0 |
11.88 |
42.1 |
|
|
|
DO-15 |
31.10 |
34.40 |
1 |
5 |
28.0 |
11.01 |
45.4 |
|
|
|
DO-15 |
33.30 |
36.80 |
1 |
5 |
30.0 |
10.33 |
48.4 |
|
|
|
DO-15 |
36.70 |
40.60 |
1 |
5 |
33.0 |
9.38 |
53.3 |
|
|
|
DO-15 |
40.00 |
44.20 |
1 |
5 |
36.0 |
8.61 |
58.1 |
|
|
|
DO-15 |
44.40 |
49.10 |
1 |
5 |
40.0 |
7.75 |
64.5 |
|
|
|
DO-15 |
47.80 |
52.80 |
1 |
5 |
43.0 |
7.20 |
69.4 |
|
|
|
DO-15 |
50.00 |
55.30 |
1 |
5 |
45.0 |
6.88 |
72.7 |
|
|
|
DO-15 |
53.30 |
58.90 |
1 |
5 |
48.0 |
6.46 |
77.4 |
|
|
|
DO-15 |
56.70 |
62.70 |
1 |
5 |
51.0 |
6.07 |
82.4 |
|
|
|
DO-15 |
60.00 |
66.30 |
1 |
5 |
54.0 |
5.74 |
87.1 |
|
|
|
DO-15 |
64.40 |
71.20 |
1 |
5 |
58.0 |
5.34 |
93.6 |
|
|
|
DO-15 |
66.70 |
73.70 |
1 |
5 |
60.0 |
5.17 |
96.8 |
|
|
|
DO-15 |
71.10 |
78.60 |
1 |
5 |
64.0 |
4.85 |
103.0 |
|
|
|
DO-15 |
77.80 |
86.00 |
1 |
5 |
70.0 |
4.42 |
113.0 |
|
|
|
DO-15 |
83.30 |
92.10 |
1 |
5 |
75.0 |
4.13 |
121.0 |
|
|
|
DO-15 |
86.70 |
95.80 |
1 |
5 |
78.0 |
3.97 |
126.0 |
|
|
|
DO-15 |
88.80 |
97.60 |
1 |
5 |
80.0 |
3.86 |
129.6 |
|
|
|
DO-15 |
94.40 |
104.00 |
1 |
5 |
85.0 |
3.65 |
137.0 |
|
|
|
DO-15 |
100.00 |
111.00 |
1 |
5 |
90.0 |
3.42 |
146.0 |
|
|
|
DO-15 |
111.00 |
123.00 |
1 |
5 |
100.0 |
3.09 |
162.0 |
|
|
|
DO-15 |
122.00 |
135.00 |
1 |
5 |
110.0 |
2.82 |
177.0 |
|
|
|
DO-15 |
133.00 |
147.00 |
1 |
5 |
120.0 |
2.59 |
193.0 |
|
|
|
DO-15 |
144.00 |
159.00 |
1 |
5 |
130.0 |
2.39 |
209.0 |
|
|
|
DO-15 |
155.00 |
171.00 |
1 |
5 |
140.0 |
2.20 |
226.8 |
|
|
|
DO-15 |
167.00 |
185.00 |
1 |
5 |
150.0 |
2.06 |
243.0 |
|
|
|
DO-15 |
178.00 |
197.00 |
1 |
5 |
160.0 |
1.93 |
259.0 |
|
|
|
DO-15 |
189.00 |
209.00 |
1 |
5 |
170.0 |
1.82 |
275.0 |
|
|
|
DO-15 |
200.00 |
220.00 |
1 |
5 |
180.0 |
1.71 |
291.6 |
|
|
|
DO-15 |
211.00 |
232.00 |
1 |
5 |
190.0 |
1.62 |
307.8 |
|
